rod end linear actuator load cell force sensor
LCB400

Rod End Load Cell

4 Products
settings
Item Number
Load Capacity
Thread Size
Outer Diameter In Inches
Height In Inches
Length In Inches
Width In Inches
Environmental Conditions
Features
Output Type
Connection Type
# Of Bridges/channels
Connector Type
Load Directions
Nonrepeatability
Max Operating Temperature
Min Operating Temperature
Max Excitation
Nonlinearity
Input Resistance
Safe Overload
Ip / Nema Rating
Material
Weight In Lb
Description
Custom Special
Temperature Shift Span
Max Compensated Temperature
Temperature Shift Zero
Min Compensated Temperature
1000 lb
3/4-16
1.5
4.3
2.2
1.5
RoHS
mV/V
Connector
1
6 Pin Bendix Receptacle, PT02E-10-6P
Tension & Compression
0.1 %RO
200 F
-60 F
18 VDC
0.5 %RO
350 Ohm
150 %RO
IP64
2024-T4
0.4375
LCB400 , 1000 lb , Tension & Compression Rod End Load Cell , RoHS Compliant, Material - 2024-T4 , 3/4-16-Thread , 6 Pin Bendix Receptacle, PT02E-10-6P
N
0.01 TSS
160 F
0.005 TSZ
60 F
3000 lb
3/4-16
1.5
4.3
2.2
1.5
RoHS
mV/V
Connector
1
6 Pin Bendix Receptacle, PT02E-10-6P
Tension & Compression
0.1 %RO
200 F
-60 F
18 VDC
0.5 %RO
350 Ohm
150 %RO
IP64
17-4 PH S.S.
1.0625
LCB400 , 3000 lb , Tension & Compression Rod End Load Cell , RoHS Compliant, Material - 17-4 PH S.S. , 3/4-16-Thread , 6 Pin Bendix Receptacle, PT02E-10-6P
N
0.01 TSS
160 F
0.005 TSZ
60 F
10000 lb
3/4-16
1.5
4.3
2.2
1.5
RoHS
mV/V
Connector
1
6 Pin Bendix Receptacle, PT02E-10-6P
Tension & Compression
0.1 %RO
200 F
-60 F
18 VDC
0.5 %RO
350 Ohm
150 %RO
IP64
17-4 PH S.S.
1.0625
LCB400 , 10000 lb , Tension & Compression Rod End Load Cell , RoHS Compliant, Material - 17-4 PH S.S. , 3/4-16-Thread , 6 Pin Bendix Receptacle, PT02E-10-6P
N
0.01 TSS
160 F
0.005 TSZ
60 F
10000 lb
3/4-16
1.5
4.3
2.2
1.5
Water Resistance
RoHS
mV/V
Connector
1
6 Pin Bendix Receptacle, PT02E-10-6P
Tension & Compression
0.1 %RO
200 F
-60 F
18 VDC
0.5 %RO
350 Ohm
150 %RO
IP65
17-4 PH S.S.
1.0625
LCB400 , 10000 lb , Tension & Compression Rod End Load Cell , RoHS Compliant, Material - 17-4 PH S.S. , 3/4-16-Thread , Special Water Resistant IP65 Rated , 6 Pin Bendix Receptacle , PT02E-10-6P
Y
0.01 TSS
160 F
0.005 TSZ
60 F

Model LCB400 is a Rod End Load Cell (Tension/Compression) designed for applications involving Inline Actuators or Hydraulic Jacks with Male/Female Threads. The standard LCB400 Rod End Load Cell (Tension/Compression) model has male/female threads, uses a lightweight 2024 Aluminum for lower capacities and a robust 17-4 Stainless Steel for the higher capacities. This model is well suited for the mid range to high range capacity requirements (1,000 lb – 10,000 lb). For any applications that require a higher capacity range, please refer to the LCB450.


Commonly industrial applications involving electric actuators require the precise measurement of the load being applied by the actuator, and thus a linear actuator with force sensor is required (e.g. force-controlled linear actuator). LCB400 load cell is suitable for direct mounting on the cylinder rod. They can, for example, be used to measure contact forces or overloads.
