QMA145 play_arrowQSH02041

3 Axis Sensor with SPI Interface

QMA145, Ch 1: 5 lb; Ch 2: 5 lb; Ch 3: 5 lb, Custom Tri-Axial Bending Beam Load Cell with Triangular Bolt Pattern, RoHS Compliant, SPI Interface
Listed price is in U.S. currency and subject to verification along with availability
Description

QMA145, 3 Axis Load Cell Force Sensor with SPI Interface.

Features
Technical Documents
Specifications
Calibration
Electrical
Mechanical
Performance
Temperature
Zero
CHANNELMINTYPMAXUNIT
Calibration Excitation
1
5
Vdc
2
5
Vdc
3
5
Vdc
Excitation
1
1
7
Vdc
2
1
7
Vdc
3
1
7
Vdc
Input Resistance
1
334
Ohms nom.
2
334
Ohms nom.
3
334
Ohms nom.
Safe Overload
1
500
% of R.O.
2
500
% of R.O.
3
500
% of R.O.
Capacity
1
5
lbs
2
5
lbs
3
5
lbs
Hysteresis
1
-0.25
0.25
% of R.O.
2
-0.25
0.25
% of R.O.
3
-0.25
0.25
% of R.O.
Nonlinearity
1
-0.25
0.25
% of R.O.
2
-0.25
0.25
% of R.O.
3
-0.25
0.25
% of R.O.
Nonrepeatability
1
-0.1
0.1
% of R.O.
2
-0.1
0.1
% of R.O.
3
-0.1
0.1
% of R.O.
Output Resistance
1
1000
Ohms nom.
2
1000
Ohms nom.
3
1000
Ohms nom.
Rated Output
1
0.5
mV/V nom.
2
0.5
mV/V nom.
3
0.5
mV/V nom.
Compensated Temperature
1
60
160
F
2
60
160
F
3
60
160
F
Operating Temperature
1
32
160
F
2
32
160
F
3
32
160
F
Temperature Shift Span
1
-0.005
0.005
% of Load/F
2
-0.005
0.005
% of Load/F
3
-0.005
0.005
% of Load/F
Temperature Shift Zero
1
-0.005
0.005
% of R.O./F
2
-0.005
0.005
% of R.O./F
3
-0.005
0.005
% of R.O./F
Zero Balance
1
-4
4
% of R.O.
2
-4
4
% of R.O.
3
-4
4
% of R.O.
+
