Digitally Configurable Analog Voltage Amplifier

FUTEK's new IAA105 digitally configurable load cell amplifier redefines strain gauge analog amplification, blending technology and engineering to meet modern force measurement demands. This versatile load cell amplifier features input options encompassing full bridge strain gauge inputs up to ±10 mV/V, making it an ideal strain gauge signal conditioner. The output choices extend up to ±10 VDC, including options like 0-1.5-3VDC and 0-2.5-5 VDC, effectively catering to load cell signal conditioning needs. Operating power, ranging from 5 to 30 VDC, can be effortlessly drawn from PC USB ports or portable battery packs, making it a convenient USB load cell solution.

The IAA105 seamlessly integrates with the new FUTEK SENSIT® LITE app, harnessing the power of Bluetooth® 5 Low Energy (BLE) Technology. Through the smartphone SENSIT® LITE app, users can easily configure settings, ranging from bandwidth to gain, and perform real-time health checks—an ideal load cell reader solution. Meeting stringent medical and aerospace standards, boasting IPC CLASS III classification, the IAA105 anticipates the demands of the next generation of mission-critical applications.

Advanced fault detection augments its capabilities, enabling swift identification of open/short circuits and high-temperature anomalies, enhancing its role as a dependable strain gage amplifier. Seamless hot swapping is facilitated by the on-board active ESD and overvoltage/current protection, ensuring uninterrupted performance. Encased in a rugged aluminum shell, the IAA105's EMI-reducing design safeguards signal integrity in diverse environments.

Precision converges with efficiency as the IAA105 achieves ultra-low noise levels of up to 2.8 mV-p-p or 10 kHz bandwidth, ensuring high-accuracy data acquisition for load cells and force sensors. Offering ±0.004% of FSR accuracy and calibration adjustments as precise as 300μV, this load cell signal conditioner empowers precision-focused applications. Moreover, with a power consumption of merely 1.2 W, the IAA105 exemplifies precision in conjunction with energy efficiency. Experience elevated accuracy and optimal performance with the IAA105, your go-to solution for load cell amplification and strain gauge signal conditioning needs
