Tension and Compression Load Cell
LRF400

Low Profile Load Cell

9 Products
settings
Item Number
Load Capacity
Thread Size
Height In Inches
Length In Inches
Width In Inches
Features
Output Type
Connection Type
# Of Bridges/channels
Connector Type
Load Directions
Nonrepeatability
Max Operating Temperature
Min Operating Temperature
Max Excitation
Nonlinearity
Input Resistance
Safe Overload
Ip / Nema Rating
Material
Weight In Lb
Custom Special
Temperature Shift Span
Max Compensated Temperature
Temperature Shift Zero
Min Compensated Temperature
0.25 lb
#10-32
2.58
2.27
0.96
Overload Protection, RoHS
mV/V
Connector
1
4 Pin Lemo Receptacle, EGG.0B.304.CLL
Tension & Compression
0.05 %RO
200 F
-60 F
18 VDC
0.05 %RO
1120 Ohm
20000 %RO
IP40
2024-T4
0.3125
N
0.005 TSS
160 F
0.005 TSZ
60 F
0.5 lb
#10-32
2.58
2.27
0.96
Overload Protection, RoHS
mV/V
Connector
1
4 Pin Lemo Receptacle, EGG.0B.304.CLL
Tension & Compression
0.05 %RO
200 F
-60 F
18 VDC
0.05 %RO
1120 Ohm
10000 %RO
IP40
2024-T4
0.3125
N
0.005 TSS
160 F
0.005 TSZ
60 F
1 lb
#10-32
2.58
2.27
0.96
Overload Protection, RoHS
mV/V
Connector
1
4 Pin Lemo Receptacle, EGG.0B.304.CLL
Tension & Compression
0.05 %RO
200 F
-60 F
18 VDC
0.05 %RO
1120 Ohm
5000 %RO
IP40
2024-T4
0.3125
N
0.005 TSS
160 F
0.005 TSZ
60 F
2.2 lb
#10-32
2.58
2.27
0.96
Overload Protection, RoHS
mV/V
Connector
1
4 Pin Lemo Receptacle, EGG.0B.304.CLL
Tension & Compression
0.05 %RO
200 F
-60 F
18 VDC
0.05 %RO
1120 Ohm
11363.6 %RO
IP40
2024-T4
0.3125
N
0.005 TSS
160 F
0.005 TSZ
60 F
5 lb
#10-32
2.58
2.27
0.96
Overload Protection, RoHS
mV/V
Connector
1
4 Pin Lemo Receptacle, EGG.0B.304.CLL
Tension & Compression
0.05 %RO
200 F
-60 F
18 VDC
0.05 %RO
1120 Ohm
5000 %RO
IP40
2024-T4
0.3125
N
0.005 TSS
160 F
0.005 TSZ
60 F
10 lb
#10-32
2.58
2.27
0.96
Overload Protection, RoHS
mV/V
Connector
1
4 Pin Lemo Receptacle, EGG.0B.304.CLL
Tension & Compression
0.05 %RO
200 F
-60 F
18 VDC
0.05 %RO
1120 Ohm
2500 %RO
IP40
2024-T4
0.3125
N
0.005 TSS
160 F
0.005 TSZ
60 F
25 lb
#10-32
2.58
2.27
0.96
Overload Protection, RoHS
mV/V
Connector
1
4 Pin Lemo Receptacle, EGG.0B.304.CLL
Tension & Compression
0.05 %RO
200 F
-60 F
18 VDC
0.05 %RO
1120 Ohm
1000 %RO
IP40
2024-T4
0.3125
N
0.005 TSS
160 F
0.005 TSZ
60 F
50 lb
#10-32
2.58
2.27
0.96
Overload Protection, RoHS
mV/V
Connector
1
4 Pin Lemo Receptacle, EGG.0B.304.CLL
Tension & Compression
0.05 %RO
200 F
-60 F
18 VDC
0.05 %RO
1120 Ohm
500 %RO
IP40
2024-T4
0.3125
N
0.005 TSS
160 F
0.005 TSZ
60 F
100 lb
#10-32
2.58
2.27
0.96
Overload Protection, RoHS
mV/V
Connector
1
4 Pin Lemo Receptacle, EGG.0B.304.CLL
Tension & Compression
0.05 %RO
200 F
-60 F
18 VDC
0.05 %RO
1120 Ohm
250 %RO
IP40
2024-T4
0.3125
N
0.005 TSS
160 F
0.005 TSZ
60 F

The Tension and Compression Load Cell offers a compact design ideal for low capacity applications. With a height of only 2.25”, the LRF400 Tension and Compression Load Cell is a great selection for tight spaces. The Standard LRF400 Tension and Compression Load Cell model has female/female threads, 2024 Aluminum construction (10 gram - 100 lb), and a Lemo Receptacle.

With all of its design features the Tension and Compression Load Cell has a high accuracy with a Nonlinearity of ±0.05%, deflection of 0.003” to 0.0011” nominal and an operating temperature of -60° F to 200° F. This Load Cell can be modified or customized to meet your requirements and most capacities are in our inventory, making them available for 24 hour shipping.

Tension and Compression Load Cell
Tension and Compression Load Cell
+
